  • PLAZMARK™ for Atmospheric Plasma

Overview

Optimal for checking large area treatments utilizing an atmospheric (normal-pressure) plasma process, the PCB Industry, the FPD Industry, or surface modification of film.

Optimal for checking large area treatments utilizing an atmospheric (normal-pressure) plasma process, the PCB Industry, the FPD Industry, or surface modification of film.
It can also be used for UV cleaning and UV ozone cleaning.

Optimal for checking large area treatments utilizing an atmospheric (normal-pressure) plasma process, the PCB Industry, the FPD Industry, or surface modification of film.

Product Video

Color Change

2 different sensitivity types are available

  • 2 different sensitivity types are available
  • High-density radical atmospheric plasma equipment [N₂+ DryAir]
    High-density radical atmospheric plasma equipment [N₂+ DryAir]

Correlation between color difference and contact angle (glass surfaces)

  • Atmospheric plasma equipment for FPD [O₂ + N₂]
    Atmospheric plasma equipment for FPD [O₂ + N₂]

Specifications

PLAZMARK™ for Atmospheric Plasma

Processing Gases (Plasma Species): O₂, N₂, Air

NEW!No. 40 (Ultrahigh Sensitivity)

Shape Long Label Sheet
Heat Resistance 100℃
Structure Substrate: Clean Paper Color Change Part: Organic Colorants, Resin
Size Substrate: 35 × 300 × 0.2 mm
Color Change Part: 300 x 15 mm
Substrate: 210 × 300 × 0.2 mm
Color Change Part: 190 x 300 mm
Quantity/Pack 20 pcs 5 sheets
Product No. PLL0430-40 PLC2130-40

No. 41 (High Sensitivity)

Shape Long Label Sheet
Heat Resistance 100℃
Structure Substrate: Clean Paper Color Change Part: Organic Colorants, Resin
Size Substrate: 35 × 300 × 0.2 mm
Color Change Part: 300 x 15 mm
Substrate: 210 × 300 × 0.2 mm
Color Change Part: 190 x 300 mm
Quantity/Pack 20 pcs 5 sheets
Product No. PLL0430-41 PLC2130-41

No. 42 (Low Sensitivity)

Shape Long Label Sheet
Heat Resistance 100℃
Structure Substrate: Clean PaperColor Change Part: Organic Colorants, Resin
Size Substrate: 35 × 300 × 0.2 mm
Color Change Part: 300 x 15 mm
Substrate: 210 × 300 × 0.2 mm
Color Change Part: 190 x 300 mm
Quantity/Pack 20 pcs 5 sheets
Product No. PLL0430-42 PLC2130-42

* Note regarding sensitivity categories: Series with smaller number values feature higher sensitivity products, meaning color change occurs under plasma processes of lower output power and shorter duration. Larger or smaller numbers within a given series have no correlation to sensitivity level.

The specifications and appearance of our products are subject to change without notice due to our efforts toward continuous improvement. Differences may be found between the color of the products portrayed in our promotional materials and the color of actual products, related to variances in photographing technique or the printing ink being used.
PLAZMARK™, Plasma Indicator™, and “Visualize the Plasma Process™” are registered trademarks of Sakura Color Corporation.
PLAZMARK™ is a registered trademark in Japan, the E.U., the U.S., and other countries.
